GAS SCREW COMPRESSORS

System solution planners benefit from an advanced portfolio of GEA screw compressors optimized for compressing natural and industrial gases.

GEA gas screw compressors are key system components in oil & gas extraction and processing operations, in power generation plants with gas turbines, in chemical processing and in numerous other industries.

The compressors are designed for long operating life and high availability and can be provided according to various guidelines, such as API 619 and other international standards.
Why screw compressors for gas compression?

Screw compressors operate by drawing gas into the spaces between the lobes of two rotors. As the rotors turn, the gas is forced by the rotor profile into continuously decreasing space until it reaches the discharge port of the compressor. The compressors do not generate out-of-balance forces; therefore, they require significantly low foundation strength.

Highlights

Medium: natural gas, biogas, process gas, synthetic gas, mixed gas
Swept volume: 231 – 13,846 m³/h / 135 – 8,149 cfm
Design pressure: 28 bar / 406 psi, 52 bar / 754 psi, other upon request
Applications: Natural gas extraction, gas storage, flare gas recovery, landfill, power plants
Design standards:
- API 619
- ATEX
- ISO10440
- UL
- Germanischer Lloyd
- Bureau Veritas
- more upon request
Speed range: 1,000-6,000 rpm (GEA Grasso M, C/D/E/G) / 1,000-4,500 rpm (GEA Grasso M, H/L/M/N) / 1,450-3,600 rpm (GEA Grasso LT)
